Details
l Casting of a host,base box structured. Precision Linear rectangular guides,Preload, steel and good, high accuracy.
l Ground-level precision ball screw, tightening and high precision.
l Interface use international standards G code instructions, carving compatible many software
l Useful and easy operate, give orders in computer,machine will follow commands and work automatically.
Specification
Model
|
MP--3030
|
X.Y working area
|
300*300mm
|
Z working area
|
100mm
|
Table
|
380*380mm
|
movement positioning accuracy
|
0.02/300mm
|
repeat positioning accuracy
|
0.01mm
|
X, Y verticality
|
0.025/300mm
|
Z space to a high degree
|
120mm
|
motor power
|
800
|
Spindle speed
|
6000-24000rpm
|
Carving max rate
|
3000mm/min
|
Driving System
|
Stepper
|
