MODEL
|
MP-360
|
MP-720
|
MP-870
|
MP-1100
|
MP-1350
|
Max Paper Width
|
360mm
|
720mm
|
870mm
|
1100mm
|
1350mm
|
Max Cutting Width
|
430mm(12" )
|
630mm(24" )
|
780mm(30" )
|
1000mm(39" )
|
1260mm(48" )
|
Motor
|
Original imported high speed stepper Motor
|
Cutting pressure/Speed
|
10-990g / 50-800mm/s
|
Cartriage
|
Whole aluminum Cartriage with Imported Gear inside.
|
Mechanical Resolution
|
0.0254mm/Step(0.001"/step)
|
Special Setting
|
Dual Cutter holders, Dual strips
|
Stands
|
Yes, All comes with Stand besides CTK-360C
|
Interface/EMS-memory
|
Serial & USB / 4M
|
Control language
|
DMPL/HPGL
|
Cutting test
|
Yes
|
Curve flat cutting
|
Yes
|
Power
|
AC90V--240V
|
Cutting knife soft loading
|
Yes
|
Working temperature
|
5C°-35C°
|
Working humidity
|
5%-95% (Non Condensing)
|
Repeatable precision(mm)
|
<+ -0.1mm
|
Type of cutter
|
Long longevity high-speed carbon alloy-steel cutter
|
Drawing instruction
|
PL/HT-GL(TM)
|
